Model

Meet

Overall Dimension **

990×490×850mm  /  39"×19"×34" inch

Carton Dimension (W/O Seat)**

1020×510×380mm  /  40"×20"×15" inch

Curb Weight (with batteries)**

42 kg / 96 lbs

Weight of Front section

14 kg / 31 lbs

Weight of Rear section

9 kg  /  20 lbs

Weight of Battery group

9 kg  /  20 lbs

Weight of Seat Assembly

8 kg /  17 lbs

Rear Tires

8×2.50" / 200×70mm Solid rubber tires

Front Tires

8×2" / 200×50 Solid rubber tires

Max.Load

125 kg  /  275 lbs

Max Forward/Reverse Speed*

7kph / 4kph / 4mph / 2.5mph

Min.Turning Radius

1080mm /  43"

Max.Gradability

16%

Ground Clearance

90mm  /  35"

Max. Kerb Height

70mm /  28"

Braking and Parking

Regenerative & Electro-Magnetic Braking

Controller

Dynamics™ DR50 PM Controller

Transmission and Motor

Sealed Trans-axle, 24V/180W PM DC Motor

Max.Range per Charge*

20 km  /  13 miles

Batteries Specification

AGM 12V12Ah × 2pcs

Batteries Weight ***

4.5 kg / 2 lbs  × 2 pcs

Charger

24V/1.8A Intelligent off-board Charger

Charging time

6~8h，110VAC~250VAC

Seat

Foldable Seat with Arm Rest

Seat Width

11500px   /  18"

Seat Depth

10250px   /   16"

Seat height from ground

500mm /   20"

Floor-board height

125mm   /  5"
