Model

C903

Overall Dimension **

1650mm×900mm×1200mm

Carton Dimension(W/O   Seat)**

1590mm×750mm×790mm

Curb Weight(with batteries)**

95 kg

Tires

10"×3.5-4   pneumatic

Max.Load

150 kg

Max Forward/Reverse Speed

10 km/h   /   6km/h

Min.Turning Radius

1200mm

Max.Gradability

16%

Ground Clearance

130mm

Max. Kerb Height

100mm

Braking and Parking

Regenerative & Electro-Magnetic   Braking

Controller

Dynamics™ DR90 PM Controller

Transmission and Motor

Sealed Trans-axle, 24V/400W PM DC Motor

Max.Range per Charge *

50km

Batteries Specification

AGM 12V20Ah   ×4pcs

Batteries Weight ***

7.3kg   ×4pcs

Charger

24V/5A Intelligent off-board   Charger

Charging time

8~10h，110VAC~250VAC

Seat

380mm × 430mm

Seat height from ground

550mm

Floor-board height

160cm

Cleaning width

90cm

Working duration per charge

＞6 hours

Cleaning efficiency

9000 square meters per hour
