Model

Life

Overall Dimension **

1380×630×1250mm  /  54"×25"×49"  inch

Carton Dimension(W/O  Seat)**

1280×640×470mm  /  50"×25"×18.5"  inch

Curb Weight(with batteries)**

88 kg  /  194 lbs

Tires

10"×3.5-4  pneumatic

Wheel-base

950mm  /  37.5"

Max.Load

150 kg / 340 lbs

Max Forward/Reverse Speed

12 kph /6kph  /   8mph /4mph

Min.Turning Radius

1535mm  /  60"

Max.Gradability

16%

Ground Clearance

125mm /  5"

Max. Kerb Height

100mm  /  4"

Braking and Parking

Regenerative &  Electro-Magnetic Braking

Controller

Dynamics™ DR90 PM Controller

Transmission and Motor

Sealed Trans-axle, 24V/500W PM DC Motor

Max.Range per Charge *

50km  /  32 miles

Batteries Specification

AGM 12V20Ah  ×4pcs

Batteries Weight ***

7.3kg /  16 lbs  ×4pcs

Charger

24V/5A Intelligent off-board  Charger

Charging time

8~10h，110VAC~250VAC

Seat

Foldable Seat with Arm  Rest

Seat Width

11500px /  18"

Seat Depth

12000px /  19"

Seat height from ground

550mm /  22"

Floor-board height

150mm  /  6"
